320 GC Hydraulic Excavator
Overview :
Category
320 GC Hydraulic Excavator
Brand
caterpillar
Engine
Model
Cat C4.4
Net Power
145 hp (metric)
Condition
Used
Operating Weight
20400 kg
Bore
105 mm
Description :
Engine
| Net Power – ISO 9249 | 143 hp |
| Net Power – ISO 9249 (DIN) | 145 hp (metric) |
| Engine Model | Cat C4.4 |
| Engine Power – ISO 14396 | 108 kW |
| Engine Power – ISO 14396 (DIN) | 147 hp (metric) |
| Bore | 105 mm |
| Stroke | 127 mm |
| Displacement | 4.4 l |
| Biodiesel Capability | Up to B20¹ |
| Emissions | Meets Brazil MAR-1 emission standards, equivalent to U.S. EPA Tier 3 and EU Stage IIIA. |
| Note (1) | Net power advertised is the power available at the flywheel when the engine is equipped with fan, air intake system, exhaust system, and alternator with engine speed at 2,000 rpm. Advertised power is tested per the specified standard in effect at the time of manufacture. |
| Note (2) | ¹Cat engines are compatible with diesel fuel blended with the following lower-carbon intensity fuels** up to: 100% biodiesel FAME (fatty acid methyl ester)* or 100% renewable diesel, HVO (hydrotreated vegetable oil) and GTL (gas-to-liquid) fuels. Refer to guidelines for successful application. Please consult your Cat dealer or “Caterpillar Machine Fluids Recommendations” (SEBU6250) for details. *For use of blends higher than 20% biodiesel, consult your Cat dealer. **Tailpipe greenhouse gas emissions from lower-carbon intensity fuels are essentially the same as traditional fuels. |
Hydraulic System
| Main System – Maximum Flow | 429 l/min (113 gal/min) |
| Maximum Pressure – Equipment | 35000 kPa |
| Maximum Pressure – Travel | 34300 kPa |
| Maximum Pressure – Swing | 25000 kPa |
Swing Mechanism
| Swing Speed | 11.3 r/min |
| Maximum Swing Torque | 74.4 kN·m |
Weights
| Operating Weight | 20400 kg |
| Note | Medium undercarriage, Reach boom, R2.9 (9’6″) stick, General Duty (GD) 1.0 m³ (1.31 yd³) bucket, 600 mm (24″) triple grouser shoes, and 3.7 mt (8,200 lb) counterweight. |
Service Refill Capacities
| Fuel Tank Capacity | 345 l |
| Cooling System | 25 l |
| Engine Oil | 15 l |
| Swing Drive – Each | 12 l |
| Final Drive – Each | 4 l |
| Hydraulic System – Including Tank | 234 l |
| Hydraulic Tank | 115 l |
Dimensions
| Boom | Reach 5.7 m (18’8″) |
| Stick | Reach 2.9 m (9’6″) |
| Bucket | 1.0 m³ (1.31 yd³) |
| Shipping Height – Top of Cab | 2960 mm |
| Handrail Height | 2950 mm |
| Shipping Length | 9530 mm |
| Tail Swing Radius | 2830 mm |
| Counterweight Clearance | 1050 mm |
| Ground Clearance | 470 mm |
| Track Length | 4250 mm |
| Length to Center of Rollers | 3450 mm |
| Track Gauge | 2380 mm |
| Transport Width | 2980 mm |
